Walk Through Metal Detector: UB600

> Detection Zones: 6 zone, 12 zone & 18 zone
> Detection mode: Bilateral Transmission Bilateral reception
> Sensitivity adjustable: Each zone has 256 sensitivity levels
> Frequency : 5.9K-8.6KHz continuously adjustable
> Minimum Detection : 1 Yuan Coin
> Visual Displays: Digital tube display
& Pass count & Alarm count (5 Digit 2 LED Display)
> Weatherproofing: IP65, Temp: -20°C to +45°C
> Remote control : 15m
> Infrared passing speed : 60/min
> Easy install
> Safe for the human body
> Support multi-language
> Warranty: 24 months (limited)
> Technical support
> optional function: wheels, CCTV system

67 people are viewing this right now
Product Description
Gross weight 65KG
Power Supply  AC100V – 240 V
Working temperature -20℃–+50℃
Working Frequency 4KHZ—8KHZ
Standard External size 2200mm(H)X800mm(W)X580mm(D)
Standard Internal size 2010mm(H)X700mm(W)X500mm(D)
Package size for door panels 2290*560*190mm *1ctn
Package size for the control unit 760*380*260 mm*1ctn




The UM-600’s Access Control Panel is designed for use by authorized personnel with specific, multi-level security with password protection, only the authorized person can operate; Sound & LED alarm: Both Side LED indicators, easily show where the metal is, Automatically count passengers, and alarm times.

  • Sound & LED alarm: Two Sides LED indicator easily shows where the metal is; 5-digit counter: Automatically count passengers and alarm times
  • Anti-interference function, using advanced interactive transmitting and receiving to avoid interference.
  • Sensitivity Test piece: One yuan Coin, omnidirectional detection
  • Password protection, only the authorized person can operate; Waterproof can be used outdoor
  • Using waterproof PVC material
  • PVC door panels, LED on the top unit
  • Sensitivity adjustable: Each zone has 2000 sensitivity level
  • 6 detecting zones, Simultaneous alarm from multi-zones
  • Easy assembly: portable design, only 4 screws, Simply follow instructions.
  • Harmless to the human body: is harmless with heart pacemakers, pregnant women, magnetic floppy, recording tapes, etc.
  • Program Self-diagnostic when power on, no need for initial or periodic calibration;
  • Modularization design, is easy for maintenance and replacement.

True quality

comes from every detail


A. 5 Digital LED Count: Easy show & count passengers;

B. 8 Screws: Easy assembly and installation;

C.Socket: Easy connect both door panels;

D. Power Line: Support UK / European / USA standards;

E. Integrated Circuit Board: Intelligent circuit;

F.Infrared Sensor: Accuracy check;

G. Tamper Indication: Easily distinguish interference;

H. Foot Cover: Easy fastness ;

Safe and harmless

Harmless to the human body: is harmless with heart pacemakers, pregnant women, magnetic floppy, recording tapes, etc.


Product packaging

Carton Dimension L*W*H (mm)

Door Panel : 2330*350*600                              Gross weight :66KG


Scope of application

It is suitable for the quick security check, where intelligent management of channels is required, such as subway stations, customs ports, airports, railway stations, hospitals, schools, communities, supermarkets, clubs, enterprises, and institutions.

Packaging and shipping

Height :

Leanth :

Product Weight :

Shipping Weight :

Accessories    .
