WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO
WALK THROUGH METAL DETECTOR: UB500 PRO

WALK THROUGH METAL DETECTOR: UB500 PRO

◆ Detection Zones: 12 zone
◆ Detection mode: Bilateral Transmission Bilateral reception
◆ Sensitivity: Each zone 0-99, 100 levels adjustable
◆ Visual Displays: Pass count & Alarm count (5 Digit LED Display)
◆ Weatherproofing: Temp: -20°C to +50°C
◆ Infrared sensor
◆ Easy install
◆ Safe for the human body
◆ Support multi-language
◆ Warranty: 12 months
◆ Technical support
◆ optional function: wheels, CCTV system

WALK THROUGH METAL DETECTOR: UB500 PRO
62 people are viewing this right now
Product Description

Elevate your safety standards with the UniqScan UB500-Pro Walk Through Metal Detector. This professional-grade walk through metal detector is the go-to choice for institutions such as airports, schools, and event spaces globally, thanks to its proven effectiveness and steadfast reliability. The UB500-Pro Walk Through Metal Detector comes with an innovative 6-zone detection system, enabling precise identification of concealed metal objects, large or small. The double-sided LED display enhances usability and efficiency, particularly in settings with high footfall. What sets the UB500-Pro apart in the realm of walk through metal detectors is its variable sensitivity settings, offering adaptability for a wide range of security requirements. The sleek design and simple assembly process allow it to be a seamless addition to any location, regardless of space constraints. Meeting all significant safety standards, including EMC, ROHS, and ISO, the UB500-Pro Walk Through Metal Detector delivers consistent performance and peace of mind. Opt for the UniqScan UB500-Pro for a walk through metal detector that combines accuracy, functionality, and user-friendliness.

Features:

  1. Six-zone Detection System: The UB500-Pro boasts a sophisticated 6-zone detection system for comprehensive and accurate detection of concealed metal objects.
  2. Variable Sensitivity Settings: Adapt the detector's sensitivity to match various security requirements, from high-stakes situations to more relaxed environments.
  3. Double-sided LED Display: Easy tracking and identification of detected objects for streamlined operations, particularly useful in high-traffic settings.
  4. Sleek, User-friendly Design: Its sleek design ensures easy assembly and installation, fitting effortlessly into any environment, even those with limited space.
  5. Compliance with Safety Standards: The UB500-Pro meets all critical safety standards, including EMC, ROHS, and ISO, ensuring dependable performance.

Benefits:

  1. Superior Security: The UB500-Pro walk through metal detector provides top-notch security, detecting a wide range of concealed metal objects effectively.
  2. Versatility: The adjustable sensitivity settings allow the UB500-Pro to be versatile for various locations and security situations.
  3. Streamlined Operation: The double-sided LED display enhances efficiency in identification and tracking, especially valuable in high-traffic environments.
  4. Easy Installation: The sleek design of the UB500-Pro allows for smooth installation, even in areas with limited space, making it a user-friendly security solution.
  5. Dependability: With adherence to CE, ROHS, and ISO safety standards, the UB500-Pro provides consistent, reliable performance
  6. Choose the UniqScan UB500-Pro Walk Through Metal Detector for an advanced, reliable, and easy-to-use security solution.
WALK THROUGH METAL DETECTOR: UB500 PRO
The UB-500 PRO's Access Control Panel is designed for use by authorized personnel with specific, multi-level security with password protection, only the authorized person can operate; Panel display function digital display, counting the number of passing and the number of alarms.
  • Easy assembly: designed with only 2 pieces of cables and 8 screws, simply-to-follow instructions
  • Alarm strength indicator on the control panel; Password protection, only the authorized person can operate.
  • Sound & LED alarm: Both Side LED indicator
  • 12 zones, Sensitivity adjustable: Each zone has 100 sensitivity level
  • Program Self-diagnostic when power on,
  • no need initial or periodic calibration;
  • Modularization design, easy for maintenance and replacement
  • Using high-density fireproof material;
  • Program Self-diagnostic when power on, no need initial or periodic calibration
  • Harmless to the human body: is harmless
  • with heart pacemakers, pregnant women, magnetic floppy, recording tapes, etc.

We own all of the intellectual property rights (IPR) to its core technologies and have an experienced engineering team. Our excellent technical development capacity supports us are able to have continuously new production lines. The Uniqscan metal detector is a leader in global safe drilling and handheld metal detection products and training. From the Olympics to international airports around the world, Uniqscan has reliable experience, expertise, and reliable products to make your facilities or events safer.

TRUE QUALITY

WALK THROUGH METAL DETECTOR: UB500 PRO

SAFE & HARMLESS

Harmless to the human body: is harmless with heart pacemakers, pregnant women, magnetic floppy, recording tapes, etc.
WALK THROUGH METAL DETECTOR: UB500 PRO

CERTIFICATIONS

WALK THROUGH METAL DETECTOR: UB500 PRO

SCOPE OF APPLICATION

It is suitable for quick security checks, where intelligent management of channels is required, such as subway stations, customs ports, airports, railway stations, hospitals, schools, communities, supermarkets, clubs, enterprises, and institutions.
WALK THROUGH METAL DETECTOR: UB500 PRO








Document Download


WALK THROUGH METAL DETECTOR: UB500 PRO





Technical Data
model UB500 PRO
Voltage AC100V-240V
working environment -20℃–+50℃
working frequency 4KHZ—8KHZ
Dimensions (mm) 2200(H)*800(W)*580(D)
Channel size (mm) 2010(H)*700(W)*500(D)
Chassis specification (mm) 2260*550*235 *1ctn
Case packaging (mm) 750*340*200 *1ctn
Net weight (kg) 60
Location display Zone 12
Detection mode Bilateral transmission Bilateral reception
Sensitivity 100 levels adjustable
Metal removal Bras, buttons, belts, jewelry, etc.
Sound and light alarm function Yes
Password protection function Yes
Protection ability Only indoor or outdoor on sunny days
Packaging and shipping
WALK THROUGH METAL DETECTOR: UB500 PRO
SIZE PARAMETERS
Chassis size 700(H)*330(W)*200(D)mm
Door size 2205(H)*500(W)*80(D)mm
Passageway Interior Size 1990(H)*700(W)*500(D)mm
Overall Exterior Size 2200(H)*860(W)*580(D)mm
Shipping Size 2280(H)*570(W)*210(D)mm (Door panel)
770(H)*390(W)*280(D)mm(Control unit )
Product Weight 52kg
Shipping Weight 60kg
Carton Dimension L*W*H (mm)
Door Panel 2280(H)*570(W)*210(D)mm
Control Unit 770(H)*390(W)*280(D)mm
Accessories
WALK THROUGH METAL DETECTOR: UB500 PRO

Details:

  • A. 5 Digital LED Count: Easy show & count passengers;
  • B. 8 Screws: Easy assembly and installation;
  • C. Socket: Easy connect both door panels;
  • D. Power Line: Support UK / European / USA standards;
  • E. Integrated Circuit Board: Intelligent circuit;
  • F. Infrared Sensor: Accuracy check;
  • G.  Tamper Indication: Easily distinguish interference;
  • H. Foot Cover: Easy fastness ;
Download
