Camera
|
|
Image sensor
|
1/2.8″ Sony 2MP CMOS sensor
|
|
Min. illumination
|
Color: 0.02Lux/F1.4,B/W:0.002Lux/F1.4
|
|
IR distance
|
/
|
|
Electronic shutter
|
Auto/ Manual(1/5~1/100000),FLK
|
|
Day/ Night
|
ICR switch,auto,color,B/W,
|
|
Lens
|
3.6mm lens
|
|
Lens interface
|
M12
|
|
S/N ratio
|
≥50db (AGC OFF)
|
|
WDR
|
WDR(Off/Low/Middle/High)
|
|
Lightboard control
|
Auto/ Manual/Off
|
|
3D N/R
|
Off/ Low/ Middle/ High/ Higher
|
|
Defog
|
Off/ Low/ Middle/ High
|
|
Mirror
|
Off/ Horizontal/ Vertical/ 180º rotation/ Corridor mode(90º rotation,270º rotation)
|
|
Slow Shutter
|
Off/On, default off
|
|
Exposure control
|
Auto/ Manual
|
|
Image setting
|
Brightness,Contrast,Saturation,Sharpness,Hue,White Balance
|
|
AUDIO/VIDEO ENCODING
|
|
Video compression
|
H.265/ H.264
|
|
H.265 Encoding
|
Main Profile
|
|
H.264 Encoding
|
Baseline / Main Profile / High Profile
|
|
Encoding features
|
NTSC: mainstream: 1920X1080@30fps,sub-stream: D1@30fps
PAL: mainstream: 1920X1080@25fps,sub-stream: D1@25fps
|
|
Third stream
|
NTSC/PAL：1920X1080@10fps
|
|
Video bit rate
|
Constant bit rate, variable bit rate (16kbps~8000kbps)
|
|
Video type
|
Complex stream/ Video stream
|
|
Audio compression
|
G.711u
|
|
Audio bit rate
|
64Kbps
|
|
Audio control
|
Input volume（0-100）, output volume（0-100）
|
|
ROI
|
Support 4 zones,multi-stage level
|
|
NETWORK
|
|
Network protocol
|
TCP/IP,UDP,HTTP,DHCP,RTSP,DDNS,NTP,PPPoE,UPnP,SMTP,FTP
|
|
Access protocol
|
ONVIF,GB28181 (optional)
|
|
Browser
|
Support IE11
|
|
Video preview meanwhile
|
8
|
|
User permission
|
User add/ modify/ delete,permission management
|
|
Safe mode
|
Authorized user name and password, HTTPS encryption and AES link encryption, RTSP verification
|
|
Motion detection
|
Set detection zone, Multi-level sensitivity can be set
|
|
Tampering alarm
|
1 zone
|
|
Privacy Mask
|
4 zones
|
|
Intelligent analysis
|
Target Counting, Retrograde Detection, Off-site Detection, Electronic Fence
|
|
Event linkage
|
Snapshot, TF card video, FTP upload or Email sending, alarm output linkage, preset linkage
|
|
Multicast function
|
Support
|
|
ANR
|
Support, match with NVR
|
|
Mobile Surveillance
|
Support Apple, Android
|
|
Device exception detection
|
Support network disconnected, IP conflict, illegal access alarm.
|
|
OSD
|
Title,time and date overlay,multi-line OSD,OSD color optional
|
|
DST
|
Support
|
|
Snapshot
|
Support snapshot; snapshot resolution is encoding resolution.
|
|
System update
|
Support remote update
|
|
HUMAN AND VEHICLE SHAPE DETECTION
|
|
Target Counting
|
The deployment time period can be set
|
|
Type of protection: personnel, vehicles, people, and vehicles
|
|
Test line can be set up, up to 4
|
|
Statistical methods: A→B/B→A, the number of people increased or decreased
|
|
Electronic Fence
|
Setup time can be set
|
|
Test line can be set up, up to 4
|
|
Detection type: target entry, exit, wander, or intrusion detection
|
|
Retrograde Detection
|
Setup time can be set
|
|
Test line can be set up, up to 4
|
|
Off-site Detection
|
Setup time can be set
|
|
Test line can be set up, up to 4
|
|
Departure time is available
|
|
Report statistics
(valid with TF card)
|
Target count: daily/monthly reports, line charts, bar charts, lists
|
|
Electronic fencing: lists
|
|
INTERFACE
|
|
Network interface
|
RJ45 10M/100M network adaptive
|
|
Audio
|
1CH（Line in）\1CH（Line out）
|
|
Alarm input
|
2CH input
|
|
Alarm output
|
1CH output
|
|
Reset
|
Support
|
|
RS485
|
Support
|
|
TF card
|
Support Max 128G,Micro SD(SDHC /SDXC) card local-storage
|
|
GENERAL
|
|
Operating temperature
|
-20°C ~ 55°C
|
|
Operating humidity
|
0﹪-90﹪
|
|
Protection grade
|
IP66/ IK09
|
|
Power supply
|
DC12V /PoE optional
|
|
PoE
|
Optional
|
|
Power consumption (max)
|
<8W
|
|
Dimensions(mm)
|
117（D）mm×86(H)mm
|
|
Weight/PCS(g)
|
650g
|
