Model
|
UNIQ-S7158/200W 10X
|
|
|
Zoom module
|
|
Image sensor
|
1/2.8″Sony 2.13M CMOS Sensor
|
|
Min. illumination
|
Color: 0.01 Lux@F1.6; B/W: 0.001Lux@F1.6, 0Lux(IR ON)
|
|
Effective pixels
|
2MP
|
|
Resolution
|
More than 1000TVL
|
|
Optical zoom
|
10X
|
|
Digital zoom
|
/
|
|
Focal Length
|
f=4.7mm~47mm
|
|
Iris
|
F1.6(W)~F3.0（T）
|
|
Angle Of View
|
60.9°（Wide）~6.43°(Tele)
|
|
Zoom speed
|
1-10 level
|
|
Focus mode
|
Auto/ Manual
|
|
Focus area
|
Full area/center area
|
|
S/N ratio
|
＞50dB
|
|
Image Adjust
|
Support brightness, contrast, saturation, Hue
|
|
White balance
|
Auto/Custom/Lock white balance / incandescent / warm / natural / fluorescen
|
|
Image mode
|
Standard/gorgeous/natural
|
|
Iris control
|
Auto/ Manual
|
|
Exposure mode
|
Auto face exposure/Manual exposure
|
|
Electronic shutter
|
Auto/ Manual (1/25~1/10000), FLK
|
|
Auto slow shutter
|
On/Off
|
|
Gain control
|
Lower/Low/Middle/High
|
|
BLC
|
Off/HLC/BLC
|
|
Dark compensation
|
/
|
|
Exposure compensation
|
/
|
|
WDR
|
TWDR/DWDR/Off
|
|
Day/Night
|
ICR switch, auto, color, B/W, ext.
|
|
Mirror
|
Normal/ Horizontal Mirror/Vertical Mirror/180º rotation
|
|
DNR
|
Off/ Low/ Middle/ High/ Higher
|
|
Defog
|
Off/ Low/ Middle/ High
|
|
Anti-shake
|
Off/ Low/ Middle/ High
|
|
AUDIO/VIDEO COMPRESSION
|
|
Video compression
|
H.264/H.265
|
|
H.265 encoding Type
|
|
|
H.264 encoding Type
|
Base Line / Main Profile / High Profile
|
|
Frame rate
|
1~30fps /1920×1080，1280×960，1280x720，720×576
|
|
|
Main stream resolution
|
1920×1080(1080p) ，1280x960(960p)，1280x720(720p)，720x576(D1)，640x480(VGA)，352x288(CIF)
|
|
Sub stream resolution
|
720x576(D1)，640x480(VGA)，352x288(CIF)
|
|
Triple stream
|
1920×1080(1080p)@10fps ，1280x960(960p)@20fps，1280x720(720p)@25fps，720x576(D1)，640x480(VGA)，352x288(CIF)
|
|
Output format
|
PAL/NTSC adjustable
|
|
Max. resolution
|
1920X1080
|
|
|
Video bit rate
|
Constant bit rate, Variable bit rate（16kbps-8000kbps）
|
|
Stream type
|
Complex stream/ Video stream
|
|
Audio compression
|
G.711u
|
|
Audio bit rate
|
64Kbps
|
|
Audio control
|
Input volume（0-100）, Input volume（0-100）
|
|
ROI
|
8 zones（1-6）
|
|
Watermark function
|
/
|
|
FUNCTION
|
|
Pan range
|
360° endless
|
|
Tilt range
|
0°~ 90°
|
|
Manual control
|
0.1°~200°/s
|
|
Preset speed
|
240°/s
|
|
Preset accuracy
|
0.1°
|
|
Preset
|
256
|
|
Cruise
|
8 groups
|
|
Linear Scan
|
/
|
|
Pattern
|
4 groups
|
|
Continuous scan
|
Support
|
|
Proportion zoom
|
Auto
|
|
PTZ watch
|
Off/ Preset/ Cruise/ Pattern
|
|
Auto flip
|
Mechanical Flip
|
|
Power off memory
|
Support
|
|
3D positioning
|
Support
|
|
Magnification / Coordinate display
|
Support
|
|
IR irradiation angle
|
Automatically grouping adjusted, depending on the zoom ratio
|
|
IR distance
|
80m
|
|
Smart IR
|
IR irradiation brightness and angle can be adjusted depending on the zoom ratio.
|
|
NETWORK
|
|
Network protocol
|
IPv4,TCP,UDP,HTTP,HTTPS,SMTP,FTP,NTP,DNS,DDNS,DHCP,ARP,UPnP,RTSP,RTP,RTCP, IGMP,PPPoE,ICMP,SNMP
|
|
Access protocol
|
ONVIF GB/T28181
|
|
Browser
|
Support IE11
|
|
Video preview meanwhile
|
8CH
|
|
User permission
|
User Add / Delete / Modify, Administrator/ Operator/Ordinary users
|
|
Safe mode
|
Authorized user name and password
|
|
Motion detection
|
Multi areas, multi-level sensitivity threshold optional
|
|
Tampering alarm
|
1 zone
|
|
Privacy mask
|
8 zones
|
|
Event linkage
|
Snapshot, TF card video, FTP upload or Email sending, alarm output linkage, Preset linkage
|
|
Multicast function
|
On/Off
|
|
ANR
|
Support, match with the NVR
|
|
Mobile Surveillance
|
Support Android, Apple
|
|
Device exception
|
Support network disconnected, IP conflict, illegal access alarm
|
|
OSD
|
Title, time and date overlay, OSD color/size adjustable
|
|
DST
|
Support
|
|
System upgrade
|
Support online remote upgrade
|
|
Other
|
/
|
|
AI
|
|
Face detection number
|
detect 30 static or 10 dynamic face targets simultaneously
|
|
Recognition face size
|
Face pixel ≥80 pixels
|
|
Posture
|
Capture within 20 degrees in vertical, 20 degrees in horizontal
|
|
Face deduplicate
|
Support
|
|
Face quality filtering
|
Support
|
|
Dynamic exposure
|
Support
|
|
Face database capacity
|
Support built-in 10000 faces
|
|
Recognition area
|
Full image recognition, support zone optional setting
|
|
Upload mode
|
FTP, SDK function calling upload
|
|
Human and vehicle shape detection
|
Target Counting、Electronic Fence、Retrograde Detection、Off-site Detection
|
|
INTERFACE
|
|
Network interface
|
RJ45 10M/100M Network Adaptive
|
|
Analog video output
|
/
|
|
Audio
|
/
|
|
Alarm input
|
1CH input
|
|
Alarm output
|
1CH output
|
|
Reset
|
Support
|
|
RS485 port
|
/
|
|
TF card
|
Support Max 128G, Support NFR
|
|
Other
|
/
|
|
GENERAL
|
|
|
Protection grade
|
IP66
|
|
Operating temperature
|
Outdoor: -30℃～50℃(Support 30 minutes delay to boot up under low temperature )
|
|
Operating humidity
|
10﹪~90﹪RH ( No condensation)
|
|
Power supply
|
DC24V/1.5A（±10%）
|
|
POE
|
Support, (IEEE802.3at standard)
|
|
Power consumption (max.)
|
30W
|
|
Dimensions(mm)
|
291(H)*149(D)mm
|
|
Weight/PCS(g)
|
4kg
|
